Parker Suction and Return Line Hose - 811-32

$111.62
0 LEFT IN STOCK
Product description

Parker’s 811 hose is a suction and return line hose that has a working pressure range of 62-300 PSI which is designed for high temperature applications

Hose I.D. (inch)  2
Hose I.D. (mm) 50,8
Hose I.D. (DN) 50
Hose O.D. (inch) 2.5
Hose O.D. (mm) 63,6
Maximum Working Pressure (psi) 100
Maximum Working Pressure (Mpa) 0,7
Hose Inner Tube Material Synthetic rubber
Material - Hose Reinforcement Multiple layers of fiber spiral and one helical wire
Hose Cover Material Synthetic rubber
Minimum Bend Radius (inch) 6
Minimum Bend Radius (mm) 152
Weight (lbs/ft) 1.26
Weight (kg/m) 1,87
Minimum Working Temperature (F) -40
Maximum Working Temperature (F) 212
Minimum Working Temperature (C) -40
Maximum Working Temperature (C) 100
Industry Standards SAE 100R4, J1942 / USCG HF
Hose Cover Type Standard
Compatible Fittings 81 Series or 88 Series Fittings
Application

  Petroleum base hydraulic fluids and lubricating oils

 Part Number

 811-32
